How To Use The Chart
Important – Your rifle should be shot from a well-padded rest, under calm wind conditions, resting forearm, not barrel on pad.

Four Steps to adjust micrometer and telescope sights

1.       Locate on the chart the exact centre of at least three carefully fired shots, using the same hold and sight setting. For example, suppose the centre of group is small circle in the upper right hand quarter of the chart, identified by the arrow.

2.       Following the vertical line we come to the figure 3L. This means that to bring the next group onto the vertical centre line requires that you move your rear sight 3 minutes of angle to the LEFT. If your sight reads in minutes-of-angle this means you must give it 3 clicks to the LEFT. If in ½ minutes-of-angle, 6 clicks and if in ¼ minutes-of-angle, 12 clicks.

3.       Now follow the horizontal line to the edge of the chart and we come to the figure 3D. This means you must move DOWN the sight 3 minutes-of-angle to bring your next group onto the horizontal centre line.

4.       If your aim was steady and correct on the first group and no puff of win blew any of your shots out of the group, your next group should be in and around the 10 ring. Your rifle is then sighted in for the range and ammunition used.
